Innovation from Swashdrive - a sleek, lightweight, slimline tattoo machine that really does make it seem like you are tattooing with a brush. The new brushless motor powering these machines is an EC (Electronic Computation) technology in small powerful DC electric motors.
Stainless Steel K Mount Bolt
32mm Composite Grip
Rigid and Give pushbars.
Startup voltage is 9 volts which is the minimum voltage required to power up the electronic circuit board that controls the motor.
9 volts at start-up will deliver 2000 rpm or 33 CPS.
11 volts = 3000 rpm / 50 CPS
13 volts = 6000 rpm / 100 CPS
16 volts = 9000 rpm / 150 CPS
Motor is limited to 150 CPS @16 volts which is max power.
